Mourad Metals is a reliable manufacturer and supplier located in Tunis, Tunisia, focusing on high-performance nickel-iron-chromium alloys tailored for tough industrial applications. They provide Incoloy 800H Forgings, crafted to exact specifications and adhering to international standards. With state-of-the-art production facilities, rigorous quality control, and knowledgeable technical support, Mourad Metals caters to sectors like chemical processing, petrochemical, power generation, and marine engineering. Their dedication to reliability, quality, and prompt delivery has made them a go-to partner for clients both regionally and globally.
Incoloy 800H is a nickel-iron-chromium alloy that includes small amounts of carbon, titanium, and aluminum, specifically engineered for high-temperature environments. It boasts improved creep and rupture strength compared to standard Incoloy 800, while also offering excellent resistance to oxidation, scaling, and carburization. Incoloy 800H Forgings deliver high tensile and yield strength, outstanding thermal stability, and dependable performance even under prolonged exposure to elevated temperatures.
Specifications ASTM B564 / ASME SB564, AMS 5766
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | Ni | Fe | Cr | Cu | Ti | Al | C | Mn | S | Si |
| Alloy 800H | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .15-.60 | .15-.60 | .05-.10 max | 1.5 max | .015 max | 1.0 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | Psi – 30,000 , MPa – 205 | 30 – 35 % |
| Density | 0.287 lb/in3 / 7.94 g/cm3 |
| Melting Point | 2475 – 2525 °F/ 1357 – 1385 °C |
| Specific Heat @ 70°F | 0.11 Btu/lb•°F |
| Permeability @ 70°F Annealed | 1.014 (200 Oersted) |
| Curie Temperature | -115 °C/ -175 °F |
| Elastic Modulus | 28.50 X 106 psi |
| Electrical Resistivity @ 70°F | 595 ohm•circ mil/ft |
| Annealling Incoloy 800 | 983 – 1038 °C / 1800 – 1900 °F |
| Annealling Incoloy 800H / Ht | 1147 – 1177°C / 2100 – 2150 °F |
| Quench | Rapid Air / Water |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 800H | N08810 | 1.4958 | Z8NC32-21 | X10NiCrAlTi32-20 | NCF 800H | NA 15(H) | ЭИ670 | XH32T |
The ideal temperature range for forging Incoloy 800H is between 2100°F and 2250°F (1149°C to 1232°C). This range ensures optimal workability and preserves the material’s mechanical properties.
Post-forging operations for Incoloy 800H typically include annealing to relieve stress and enhance ductility, followed by heat treatment to achieve desired mechanical properties. Surface cleaning and inspection for defects are also essential to ensure quality.
To determine if Incoloy 800H Forgings meet your specific needs, review material specifications, including composition and mechanical properties, and consult with suppliers for customized testing or performance data. Additionally, consider your application's temperature, corrosion, and mechanical requirements.
These Incoloy 800H Forgings find extensive use in applications that demand high-temperature strength, oxidation resistance, and long-lasting durability. They’re often utilized in furnace components, heat exchangers, chemical processing equipment, pressure vessels, and piping systems. The alloy is also prevalent in power generation, petrochemical, and marine sectors where performance at high temperatures is crucial. Thanks to its blend of creep resistance, corrosion resistance, and mechanical strength, Incoloy 800H is perfectly suited for challenging high-temperature industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Mourad Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Tunis, Tunisia
