Mourad Metals, located in Tunis, Tunisia, stands out as a top-notch manufacturer and supplier of high-quality phosphorous bronze bars and rods. Known for their precision engineering and outstanding material integrity, Mourad Metals provides products that adhere to strict industrial standards. With years of experience in the metallurgy field, the company guarantees consistent quality, dependable supply, and customized solutions to meet a variety of industrial needs. Their phosphorous bronze bars and rods are produced using cutting-edge techniques, ensuring excellent durability, corrosion resistance, and superior conductivity. Mourad Metals is dedicated to serving clients in the mechanical, electrical, and engineering sectors with professionalism and excellence.
Phosphorous bronze bars and rods mainly consist of copper, with 0.5–11% tin and 0.01–0.35% phosphorus, which boosts their strength, wear resistance, and corrosion resistance. The phosphorus content also enhances the material’s stiffness and fatigue resistance, making it perfect for demanding applications. These bars and rods are known for their excellent machinability, high tensile strength, and good dimensional stability. They feature a smooth surface finish and can handle mechanical stress without deforming. Their non-sparking and anti-friction properties make them ideal for precision instruments, springs, and bearings, ensuring both durability and reliability in tough operational conditions.
| Specifications | AMS 4625, ASTM B139, ASME SB139 |
| Phosphor Bronze Round bar size | Diameter: 3mm~800mm |
| Phosphor Bronze Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Phosphor Bronze Square bar size | 4mm*4mm~100mm*100mm |
| Phosphor Bronze Flat bar size | Thickness: 2mm~100mm |
| Width: 10mm~500mm | |
| Phosphor Bronze Hex Bar size | 2mm~100mm |
| Phosphor Bronze Billet Size | 1/2″ to 495mm Diameter |
| Phosphor Bronze Rectangles Size | 33mm x 30mm to 295mm x 1066mm |
| Finish | Bright, Polish, Bright, Rough Turned, Grinding, Centreless Ground & Black |
| Length | 1000mm-6000mm |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline |
| Condition | Cold Drawnd Pulished Cold Drawn Centreless Ground & Polished, Annealed round bar |
| Technique | Phosphor Bronze Hot Rolled, Cold Rolled, Cold Drawn, Forged Round Bar, Rod |
| Form | Round, Rod, Precision Ground Bar, Square, Round Rod, Hollow, Hex (A/F), Triangle, Rectangle, Threaded, T-Bar, Half Round Bar, Flat Bar, Rings, Blocks, Billet, Ingot, I/H Bar, Angle, Channel Bar, Profiles, Forging Etc. |
| Alloy number | Sn | P | Pb | Zn | Cu+Sn+P |
| C5191 | 5.5-7.0 | 0.03-0.35 | ≥99.5 | ||
| C5441 | 3.0-4.5 | 0.01-0.50 | 3.5-4.5 | 1.5-4.5 | ≥99.5 |
| Grade B.S. 1400: 1985 | Nominal Composition | 2% PS N/mm Min | Tensile Strength N/mm Min | Elongation % Min | Brinell Hardness Min |
| PB1 | 89/10/01 | 130 | 250 | 5 | 60 |
| PB1 | 88/12 | 140 | 260 | 7 | 80 |
| PB1 | 90/10 | 130 | 250 | 5 | 60 |
| PB1 | 90.5/9.5 | 130 | 240 | 5 | 80 |
| LPB-1 | 87/8/2/3 | 80 | 175 | 7 | 60 |
| Pb2 | 88/12 | 120 | 195 | 5 | 60 |
| Pb2 PB | 88/12 95/5 | 145 130 | 295 240 | 5 5 | 80 80 |
Phosphorus bronze bars can be welded, but it requires care. The material tends to be brittle at high temperatures, so preheating and using appropriate filler materials are recommended for successful welding.
To select the right phosphorous bronze bar, consider factors such as tensile strength, corrosion resistance, conductivity, the specific environmental conditions, required durability, and mechanical properties for your application.
To select the right phosphorous bronze bar, consider factors such as tensile strength, corrosion resistance, conductivity, the specific environmental conditions, required durability, and mechanical properties for your application.
Phosphorous bronze rods are available in diameters ranging from 1/8" to 12" and lengths up to 20 feet. Finishes include hot-rolled, cold-rolled, extruded, polished, and custom-machined.
Phosphorous bronze bars and rods are extensively used in industries that require high strength, wear resistance, and corrosion protection. They are perfect for creating electrical connectors, springs, bushings, and bearings due to their excellent conductivity and low friction characteristics. The material’s resistance to seawater corrosion makes it a great choice for marine applications, including propellers, pumps, and valve components. Additionally, phosphorous bronze finds its place in aerospace, automotive, and mechanical engineering for gears, fasteners, and precision instruments. Its combination of properties makes it a go-to material for various demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
