Mourad Metals, located in Tunis, Tunisia, stands out as a top-notch manufacturer and supplier of premium Copper Nickel 95/5 Bars and Rods. Known for their precision engineering and strict quality standards, Mourad Metals serves a variety of industries, including marine, chemical, and desalination sectors. Their dedication to excellence guarantees that every product offers outstanding performance, corrosion resistance, and durability. With a keen focus on both local and global markets, Mourad Metals delivers dependable, long-lasting Copper Nickel 95/5 solutions that meet rigorous specifications, supporting essential applications in challenging environments while upholding sustainable production practices.
Copper Nickel 95/5 Bars and Rods are primarily made up of 95% copper and 5% nickel, with small amounts of iron and manganese. This alloy is known for its remarkable resistance to seawater corrosion, biofouling, and erosion. On the mechanical side, it boasts good tensile strength, ductility, and toughness across a wide temperature range. Additionally, it maintains stable conductivity and thermal properties, making it perfect for demanding marine and industrial uses. Its ability to endure harsh conditions without significant wear ensures reliable long-term performance, while its workability allows for easy forging, machining, and welding.
| Standards | ASTM B151 / ASME SB151 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI all International Standards |
| Diameter | Outside Diameter in the range of 4mm to 500mm |
| Width | 1m to 48″ |
| Hex Bars | 18mm – 57mm (11/16″ to 2-3/4″) |
| Square Bars | 18mm – 47mm (11/16″ to 1-3/4″) |
| Flat Bars | 1/2” to 10” in the thickness range of 2mm to 150mm |
| Wire Length | Max 12000 mm |
| Wire Diameter | 5.5 – 400 mm |
| Length | 1 to 6 Meters, Custom Cut Lengths |
| Types | Round, Square, Hex (A/F), Flat, Square, Rectangle, Billet, Ingot, Forging, Wire Bobbin, Wire Spool, Wire Rope, Spring Wires, Welding Wire, Coiled Wire Etc. |
| STANDARD | UNS | WERKSTOFF NR. |
| Cu-Ni 95/5 | C70400 | – |
Melting Point – Liquidus°F |
2050 |
Densitylb/cu in. at 68°F |
0.323 |
Specific Gravity |
8.94 |
Electrical Conductivity% IACS at 68°F |
14 |
Thermal ConductivityBtu/ sq ft/ ft hr/ °F at 68°F |
37 |
Coefficient of Thermal Expansion 68-57210?6 per °F (68 – 572°F) |
9.7 |
Specific Heat CapacityBtu/ lb /°F at 68°F |
0.09 |
Modulus of Elasticity in Tensionksi |
17000 |
Modulus of Rigidityksi |
6400 |
Yes, Copper-nickel 95/5 bars and rods are suitable for hygienic and sanitary applications due to their antimicrobial properties, corrosion resistance, and non-toxic nature, making them ideal for water and food-related systems.
Yes, Copper-nickel 95/5 bars and rods can be recycled after use. Their high recyclability allows them to be reprocessed without significant loss of properties, promoting sustainability and resource efficiency.
Yes, Copper-nickel 95/5 bars and rods are suitable for potable water applications due to their excellent corrosion resistance, biofouling resistance, and durability, ensuring safe and long-lasting performance in water systems.
These Copper Nickel 95/5 Bars and Rods find extensive use in marine engineering, including shipbuilding, seawater piping systems, and desalination plants, thanks to their exceptional corrosion resistance. They’re also utilized in chemical processing equipment, heat exchangers, condenser tubes, and offshore structures that face saltwater exposure. Other applications include fluid handling systems, valves, pumps, and various components where durability and longevity in tough environments are essential. The alloy’s blend of mechanical strength and resistance to biofouling helps minimize maintenance needs, making it a reliable choice for critical applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
