Mourad Metals is a trusted manufacturer and supplier located in Tunis, Tunisia, recognized for providing top-notch aluminium products across various industrial sectors. The company specializes in Aluminium 7050 Bars and Rods, ensuring that their materials adhere to rigorous international quality standards. With state-of-the-art manufacturing facilities, a team of skilled professionals, and a strong dedication to precision, Mourad Metals caters to industries like aerospace, defense, marine, and heavy engineering. Their commitment to consistency, timely deliveries, and meeting customer-specific needs has established them as a reliable partner in both regional and global markets.
Aluminium 7050 is a high-strength, heat-treatable alloy primarily made up of aluminium, zinc, magnesium, and copper, along with trace amounts of other elements to boost its performance. It boasts impressive mechanical properties, including high tensile and yield strength, outstanding fatigue resistance, and good fracture toughness. Additionally, this alloy is known for its strong resistance to stress corrosion cracking, especially in thicker sections. Aluminium 7050 Bars and Rods offer excellent hardness, machinability, and structural stability, even under demanding mechanical loads.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight % | Zn | Cu | Mg | Zr | Fe | Si | Mn | Ti | Cr | Others (total) |
| Minimum | 5.7 | 2.0 | 1.9 | 0.08 | – | – | – | – | – | – |
| Maximum | 6.7 | 2.6 | 2.6 | 0.15 | 0.15 | 0.12 | 0.10 | 0.06 | 0.04 | 0.15 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 515 MPa | 74695 psi |
| Yield strength | 455 MPa | 65992 psi |
| Fatigue strength | 240 MPa | 34809 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 11% | 11% |
| UNS | EN | DIN,WNr | ISO |
| A97050 | EN3982 | 3.4144 | AlZn6CuMgZr |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 7050 bars are ideal for structural applications, particularly in aerospace and military sectors, offering high strength, corrosion resistance, and fatigue resistance, making them suitable for demanding environments and designs.
To maintain Aluminium 7050 bars, regularly clean them with mild soap and water to remove dirt and debris. Avoid harsh chemicals, inspect for corrosion, and store in a dry, cool environment.
Yes, Aluminium 7050 rods are highly recyclable. Aluminium, including alloy 7050, can be recycled multiple times without losing its properties, making it an environmentally friendly choice for sustainable manufacturing and use.
These Aluminium 7050 Bars and Rods are widely utilized in applications where strength and reliability are crucial. They’re often found in aerospace components like wing structures, fuselage frames, landing gear parts, and essential aircraft fittings. The alloy is also employed in defense systems, marine structures, and high-performance automotive components. Thanks to its remarkable mechanical strength, corrosion resistance, and durability, Aluminium 7050 is ideal for heavy engineering, precision tooling, and load-bearing structural applications that face extreme operating conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
