Mourad Metals is a reputable manufacturer and supplier located in Tunis, Tunisia, known for delivering top-notch aluminium products across various industries. The company focuses on Aluminium 7075 Bars and Rods, providing materials that meet international standards and rigorous technical specifications. With state-of-the-art production facilities, stringent quality control, and a customer-centric approach, Mourad Metals caters to sectors like aerospace, defense, marine, and heavy engineering. Their dedication to precision, reliability, and timely delivery has established them as a trusted provider of high-strength aluminium solutions both locally and globally.
Aluminium 7075 is a robust, heat-treatable alloy primarily made of aluminium, zinc, magnesium, and copper, with a touch of chromium to enhance its performance. It’s celebrated for its remarkable mechanical properties, boasting very high tensile and yield strength, excellent fatigue resistance, and commendable hardness. While it offers moderate resistance to corrosion, Aluminium 7075 Bars and Rods excel in machinability and structural stability, making them perfect for applications that demand exceptional strength and load-bearing capabilities.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight % | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Each | Total |
| Minimum | 1.20 | 2.10 | 0.18 | 5.10 | ||||||
| Maximum | 0.40 | 0.50 | 2.00 | 0.30 | 2.90 | 0.28 | 6.10 | 0.20 | 0.05 | 0.15 |
| Temper | Tensile | Hardness | ||||
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6, T651 | 83 | 572 | 73 | 503 | 11 | 150 |
| T73, T7351 | 73 | 503 | 63 | 434 | 13 | N/A |
| UNS | EN | DIN,WNr | JIS | AFNOR | ISO | BS | GOST |
| A97075 | ENAW-AlZn5.5MgCu EN AW-7075 | 3.4365 AlZnMgCu1.5 | 7075 | 7075 A-Z5GU | AlZn6MgCu | 7075 L95 L96 | V95 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 7075 bar is commonly used for structural applications due to its high strength, excellent corrosion resistance, and lightweight properties, making it suitable for aerospace, automotive, and military structural components.
Aluminium 7075 rods are sized based on their diameter and length. Diameters typically range from 1/8" to 12", and lengths vary from 3' to 20', depending on specific customer requirements.
To maintain Aluminium 7075 bar, regularly clean it with mild soap and water to remove dirt. Avoid harsh chemicals, and store it in a dry, cool environment to prevent corrosion and damage.
These Aluminium 7075 Bars and Rods find extensive use in industries where maximum strength and lightweight performance are essential. They’re commonly utilized in aerospace structures, including aircraft fittings, wing components, gears, and shafts. The alloy also plays a vital role in defense equipment, marine hardware, high-performance automotive parts, and precision tooling. Thanks to its outstanding strength-to-weight ratio and durability, Aluminium 7075 is the go-to choice for heavy engineering, sporting equipment, and structural components that face high stress and challenging operating conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
