Mourad Metals, located in Tunis, Tunisia, stands out as a top-notch manufacturer and supplier of high-quality stainless steel products, with a particular focus on STAINLESS STEEL 317 HEX BARS/RODS. Known for its unwavering dedication to quality and precision, Mourad Metals serves industries that demand high-performance materials with outstanding corrosion resistance. The company’s 317 HEX BARS/RODS are produced using cutting-edge manufacturing techniques, ensuring they boast dimensional accuracy, exceptional strength, and impressive durability. With a strong emphasis on reliability and customer satisfaction, Mourad Metals caters to a variety of sectors, delivering products that adhere to strict international standards and perform optimally in challenging industrial settings.
These Stainless Steel 317 HEX BARS/RODS are primarily made up of iron, along with 18% chromium, 12% nickel, and 3% molybdenum, plus trace amounts of carbon, manganese, and silicon. This unique blend significantly boosts their resistance to oxidation and corrosion, especially in environments rich in chlorides and acids. On the mechanical side, this material showcases excellent tensile strength, yield strength, and hardness, all while maintaining good ductility and toughness. The high molybdenum content enhances resistance to pitting and crevice corrosion, making it a great choice for high-temperature applications. The alloy consistently performs well under mechanical stress, ensuring reliability in structural and industrial applications where durability and longevity are paramount.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317 | 0.08 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 14.0 | 0.045 max. | 0.03 max. | 1.00 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 317 | 8 | 1454 ℃ | 515 | 205 | 40 | 217 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 317 hex bars/rods are commonly used in the industrial and construction sectors for their corrosion resistance and high strength. They are utilized in manufacturing chemical processing equipment, marine environments, heat exchangers, pumps, valves, fasteners, and structural components in corrosive conditions, ensuring durability and reliability.
SS 317 hex bars/rods typically range from 6 mm to 100 mm in size, with tolerances as per ASTM A276 or similar standards. Precise dimensions and tight tolerances ensure consistent strength, machinability, and fitment, making them ideal for high-performance applications in chemical, marine, and structural industries.
SS 317's chemical composition, with high levels of chromium (24-26%) and molybdenum (3-4%), enhances its resistance to pitting and crevice corrosion. The molybdenum content improves resistance to chloride-induced corrosion, while the balanced alloying helps prevent stress corrosion cracking, making it ideal for harsh, chloride-rich environments.
STAINLESS STEEL 317 HEX BARS/RODS find extensive use in the chemical processing, petrochemical, and marine industries, thanks to their remarkable corrosion resistance. They are perfect for crafting pumps, valves, heat exchangers, and storage tanks that face harsh conditions. Additionally, they are utilized in food processing equipment, pharmaceutical machinery, and architectural components where hygiene and durability are crucial. The hexagonal shape makes them easy to handle, fasten, and assemble in various mechanical applications. Industries that require resistance to both oxidizing and reducing agents will find these bars/rods particularly beneficial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
