Mourad Metals, located in Tunis, Tunisia, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Stainless Steel 321H Hex Bars and Rods, meeting a wide range of industrial needs. With a keen emphasis on precision manufacturing, unwavering quality, and adherence to international standards, Mourad Metals is known for delivering products that excel in high-temperature strength, corrosion resistance, and overall reliability. The Stainless Steel 321H Hex Bars and Rods from Mourad Metals are crafted using cutting-edge technology and rigorous quality control measures, making them perfect for demanding applications in sectors like petrochemical, power generation, and industrial fabrication around the globe.
Stainless Steel 321H is a titanium-stabilized austenitic stainless steel that boasts a higher carbon content, which boosts its high-temperature strength. Typically, its composition features chromium and nickel for corrosion resistance, titanium to stabilize against carbide precipitation, and controlled carbon levels to enhance creep resistance. On the mechanical side, Stainless Steel 321H Hex Bars and Rods provide impressive tensile strength, outstanding toughness, and excellent resistance to intergranular corrosion at elevated temperatures, along with good weldability and structural stability during extended heat exposure.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 321 | 0.08 max. | 17.0 – 19.0 | 2.00 max. | 9.0-12.0 | 0.045 max. | 0.03 max. | 0.75 max. |
| SS 321H | 0.04 – 0.10 | 17.0 – 19.0 | 2.00 max. | 9.0-12.0 | 0.045 max. | 0.03 max. | 0.75 max. |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 321 | 0.08 max. | 17.0 – 19.0 | 2.00 max. | 9.0-12.0 | 0.045 max. | 0.03 max. | 0.75 max. |
| SS 321H | 0.04 – 0.10 | 17.0 – 19.0 | 2.00 max. | 9.0-12.0 | 0.045 max. | 0.03 max. | 0.75 max. |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 321H Hex Bars/Rods are highly resistant to oxidation and intergranular corrosion due to titanium stabilization, making them ideal for high-temperature environments. They offer excellent strength, durability, and resistance to sulfur compounds, ensuring reliability in extreme conditions.
SS 321H Hex Bars/Rods are commonly used in aerospace, chemical processing, power generation, petrochemical, and pharmaceutical industries. They are ideal for high-temperature applications such as heat exchangers, pressure vessels, exhaust systems, and furnace components due to their excellent corrosion resistance.
SS 321H Hex Bars/Rods can be welded easily, thanks to their titanium stabilization, which prevents sensitization and intergranular corrosion. However, it's essential to use low-carbon filler materials to maintain the material's properties and prevent carbide precipitation. Pre-heating and post-weld heat treatment may be required for optimal results.
These Stainless Steel 321H Hex Bars and Rods find their way into various applications that demand strength and corrosion resistance at high temperatures. You’ll often see them in heat exchangers, furnace components, exhaust manifolds, expansion joints, and equipment used in petrochemical processing. They’re also essential in power generation plants, aerospace components, and high-temperature piping systems. Their hexagonal shape makes them easy to handle and allows for precise fastening in mechanical assemblies, making them a great choice for fabrication, machining, and structural applications in tough thermal and corrosive environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
