Mourad Metals is a reputable manufacturer and supplier of Titanium Grade 6 Bars and Rods, proudly based in Tunis, Tunisia. They specialize in delivering top-notch titanium products to industries around the globe. Titanium Grade 6 (Ti-5Al-2.5Sn) is a near-alpha alloy celebrated for its impressive strength-to-weight ratio, outstanding creep resistance, and stability even at high temperatures. At Mourad Metals, Grade 6 bars and rods are crafted using cutting-edge processing techniques, ensuring consistent quality, precise dimensions, and adherence to international standards. With a strong commitment to reliability and customer satisfaction, the company caters to the aerospace, marine, and industrial sectors that demand durable, lightweight, and corrosion-resistant materials.
These Titanium Grade 6 Bars and Rods are primarily made of titanium, combined with about 5% aluminum and 2.5% tin, along with carefully controlled amounts of iron and oxygen. This unique blend enhances mechanical strength, provides good weldability, and offers excellent resistance to creep and oxidation at moderately high temperatures. Mechanically, Grade 6 boasts high tensile and yield strength, good fatigue resistance, and improved thermal stability compared to commercially pure titanium. It also maintains toughness at low temperatures while ensuring corrosion resistance in marine and industrial settings, making it ideal for demanding structural applications.
| Standards : | ASTM B348, B863 / ASME SB348, SB863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr 6 | 3.7114 | R54520 |
| Grade | C | Fe | N | Ti | H | O | Al | Sn |
| Titanium Gr. 6 | .08 max | 0.50 max | .05 max | Balance | .0175 – .020 | .20 max | 4.0 – 6.0 | 2.0 – 3.0 |
| Element | Min.Tensile(KSI) | Min.Yield(KSI) | Hardness | Tensile Modulus | Poisson’s Ratio |
| Ti Grade 6 | 50 | 40 | 14.9 | 103 GPa | 0.34-0.10 |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Titanium Grade 6 Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@mouradmetals.com
Titanium Grade 6 Bars and Rods provide excellent strength-to-weight ratio, outstanding corrosion resistance, high-temperature stability, and good formability, making them ideal for high-performance applications.
Titanium Grade 6 Bars and Rods offer superior strength, corrosion resistance, and weldability, along with excellent performance in high-temperature and aggressive environments, making them suitable for critical industrial applications.
You’ll find Titanium Grade 6 Bars and Rods widely used in situations that require high strength, thermal stability, and resilience against harsh environments. In the aerospace sector, they’re often used for airframe components, engine casings, and structural parts that face elevated temperatures. The marine industry benefits from their exceptional corrosion resistance in seawater, making them perfect for shafts and fasteners. Moreover, these bars and rods find their place in chemical processing equipment, power generation systems, and high-performance industrial components where reliability, lightweight design, and long service life are crucial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
